| Basic parameters | Note | |
Fin wave height | H=4-12mm | Adjustable Customized |
Fin width | 26-105mm | Adjustable Customized |
Fin Length | Lmax=900mm | Adjustable Customized |
Number of Stacks | Nmax=8-20 items/stack | Adjustable Customized |
Splicing capacity | Nmax=70-80 articles/min | |
Conveyor | L×W×H =1510×300×1120（mm） | |
Yarding device | L×W×H =1590×2000×1580（mm） | |
Equipment weight | about 1 ton | |
Power supply | AC 220V±10% | |
Frequency | 50HZ±2% | |
Power | 3Kw | |
Air supply | pneumatic 0.4~0.8MPa | Dry, cooled and filtered compressed air |
Vibration | 70dB | |
Equipment Color | Customized according to customer's color sample requirements | |
