| Basic parameters | Note | ||
Feeding speed | Maximum speed 200m/min; (Maximum 13000 peaks/min) Stabilization speed 190m/min | 60mm-26mm Maximum speed 200m/min; 60mm-105mm Maximum speed 160m/min | |
Cutting frequency | Maximum number of times 100cuts/min (cutting frequency and fin cutting length and the number of peaks) | ||
Cutting accuracy | ±0 peaks, all cut at the top of the peaks | ||
Inner diameter of material tray | φ150mm～φ200mm(300mm extension possible) | ||
Outer diameter of material disk | ≦φ1800mm | ||
Weight of material tray | Max 500kg | ||
Tray | Single material tray | ||
Servo system | Panasonic | ||
Fin material | Aluminum Thickness 0.05～0.20mm | ||
Fin width | 26～105mm(customizable) | ||
Fin height | 4～12mm | ||
Fin length | Customized | ||
Overall Dimension | L×W×H=5152×1150×1836(mm) | ||
Machine weight | About 4.2 tons | ||
Imported oil injection system | Japanese precision type | ||
Power supply | AC 3-380V±10% | ||
Power frequency | 50HZ±2% | ||
Power supply power | 17KW | ||
Air pressure | P/0.6Mp | cooled and filtered compressed air | |
Flow rate | Q＞0.1㎥/min | ||
Equipment color | 6109 white, and color samples can be provided according to the requirements of customers. | ||
Note | It can be customized according to special requirements | ||
