GS-200 Aluminum Fin Machine

Categories：Tape making machine

Goods SN：GS-200 Aluminum Fin Machine

Detail

Basic parameters		Note
Feeding speed	Maximum speed 200m/min; (Maximum 13000 peaks/min) Stabilization speed 180m/min
Cutting frequency	Maximum number of times 100cuts/min (Cutting frequency is related to the fin cutting length and the number of peaks)
Cutting accuracy	±0 peaks, all cut at the top of the peaks
Inner diameter of material tray	φ150mm～φ200mm (300mm extension possible)
Outer diameter of material disk	≦φ1800mm
Weight of material tray	Max 500kg
Tray	Single material tray
Servo system	Panasonic
Fin material	Aluminum Thickness 0.05～0.20mm
Fin width	12～56mm(customizable)
Fin height	4～12mm
Fin length	Customized
Overall Dimension	L×W×H=5103×900×1836(mm)
Machine weight	About 4 tons
Imported oil injection system	Japanese precision type
Power supply	AC 3-380V±10%
Power frequency	50HZ±2%
Power supply power	15KW
Air pressure	P/0.6Mp	Dry, cooled and filtered compressed air
Flow rate	Q＞0.1㎥/min
Equipment color	6109 white, and color samples can be provided according to the requirements of customers.
Note	It can be customized according to special requirements
